| SV61 solenoid valve is a compact IP65 rated NAMUR mount solenoid valve that is light-weight and easy to use. This light-weight, compact solenoid offers a standard manual override and comes as a standard 4-Way with easy conversion to a 3-Way for spring return (single-acting) applications.
Features & Benefits
SV series solenoid valve is a complete range of valves designed according to NAMUR VDI/VDE 3845 and made of epoxy coated anodized aluminum. Each solenoid valve is field interchangeable for use on either double acting 4-Way or spring return 3-Way actuators and is available in single coil, dual coil, or 3-position configuration (open centers, closed centers, or center in pressure).
Manual Override
Each SV solenoid valve comes standard with a lockable manual override. This is an important feature because it allows the solenoid valve to be used manually in case of electrical failure, or for quick cycle testing.
Standard Configuration
The Max-Air SV series solenoid valve features anodized aluminum spool, easy to use manual override, and comes as 4-Way (Double Acting) with an optional adapter plate for 3-Way (Spring Return) field conversion.
Namur Mounting
Each SV series NAMUR mount solenoid valve is available in a single coil version (SV61 or SV63), dual coil (SV62), open centers (S36A), and closed centers (S36C).
Hazardous Location Options
The SV series NAMUR mount is available in various explosion proof configurations for hazardous locations. There are single coil and dual coil options available.
Air Inlet/Exhaust Port Connections
All SV solenoid valves come with 1/4\" NPT air inlet and exhaust connections. This standard connection allows for ease in connecting all airlines and retrofitting each solenoid valve with the proper speed control or muffler.
Air Service
Max-Air solenoid valves can be used with lubricated or non-lubricated air. |
